Fire Science: Wildfire Monitoring and Prediction


Fire Imaging: Cedar Fire
Cedar Fire, San Diego County, CA
26 October 2003 at 11:34


As viewed by the FireMapper™ Thermal-Imaging Radiometer


Click on the image above to view a larger Zoomify (JPEG) image
(opens a new browser window)

Current Image: Thermal mosaic
Ground surface temperatures as viewed from above at 8-12 micrometers wavelength on 26 October 2003, between 11:34 and 14:40 PDT.



Image 1: Thermal Mosaic
Plan view of fire. Warmer tones represent recent or active combustion; areas of light gray are cooling ash or warm bare ground and the low temperatures of unburned forest and cool ground are shown in darker gray (see chart above).


Click on the image above to view a larger JPEG image
(opens a new browser window)



Northwest set of repeat transects (near Poway)

Image 2: Mosaic Overlay Example
Firespread series: Pass 02 at 11:34


Entire Sequence:
View the Cedar Fire repeat coverage of this area:
Passes 2, 6, 9, 37 and 70.


Click on the image above to view a larger JPEG image
(opens a new browser window)



Image 2a: Google Earth Overlay
Firespread series: Pass 02 at 11:34


View the Cedar Fire Pass 02 in Google Earth.
Locations approximate.


Entire Sequence:

View the Cedar Fire Passes 2, 6, 9, 37 and 70 in Google Earth.
Locations approximate.




Click on the image above to view a larger JPEG image
(opens a new browser window)



Southwest set of repeat transects (near Miramar)

Image 3: Mosaic Overlay Example
Firespread series: Pass 11 at 12:12


Entire Sequence:
View the Cedar Fire repeat coverage of this area:
Passes 11, 12, 14, 15, 17, 29, 31, 33, 34, 36 and 68/69.


Click on the image above to view a larger JPEG image
(opens a new browser window)



Image 3a: Google Earth Overlay
Firespread series: Pass 11 at 12:12


View the Cedar Fire Pass 11 in Google Earth.
Locations approximate.


Entire Sequence:

View the Cedar Fire Passes 11, 12, 14, 15, 17, 29, 31, 33, 34, 36 and 68/69 in Google Earth.
Locations approximate.


Click on the image above to view a larger JPEG image
(opens a new browser window)



Eastern front with repeat transects

Image 4: Mosaic Overlay Example
Firespread series: Pass 53, 54 at 18:22

Entire Eastern Sequence:
View the Cedar Fire coverage of this area:
Passes 6, 9, 17, 31, 29, 26, 25, 51, 59, and 53/54


Click on the image above to view a larger JPEG image
(opens a new browser window)



Image 4a: Google Earth Overlay
Firespread series: Passes 51, 53, 54 at 18:22


View the Cedar Fire Pass 53, 54 in Google Earth.
Locations approximate.


Entire Sequence:

View the Cedar Fire Passes 6, 9, 17, 31, 29, 26, 25, 51, 59, and 53/54 in Google Earth.
Locations approximate.


Click on the image above to view a larger JPEG image
(opens a new browser window)

Weather conditions at time of data collection :
from NOAA ROMAN system.

ID: JULC1
NAME: JULIAN
LATITUDE: 33.0758
LONGITUDE: -116.5908
ELEVATION: 4240 ft
MNET: RAWS



Past Weather Conditions for JULC1
Observations prior to selected time: October 26, 2003 - 22:00 GMT
Weather Conditions at October 26, 2003 - 17:10 GMT

17:10 24 Hour Max 24 Hour Min
Temperature 67.0° F 81.0 at 22:10 59.0 at 2:10
Dew Point 10.8° F 25.1 at 2:10 10.8 at 17:10
Relative Humidity 11% 27 at 2:10 11 at 17:10
Wind Speed 22 mph from E 22 at 17:10 0 at 2:10
Wind Gust 42 mph 42 at 17:10 1 at 6:10
Solar Radiation 598.0 W/m*m 598.0 at 17:10 0.0 at 1:10
Fuel Temperature 71.0° F 93.0 at 22:10 49.0 at 6:10

Precipitation accumulated since midnight: 0.00", in 24 hours: 0.00"

Tabular Listing: October 25, 2003 - 21:00 through October 26, 2003 - 22:00 GMT
Time(GMT) Temperature Dew Relative Wind Wind Wind Quality Solar Precipitation Fuel
Point Humidity Speed Gust Direction check Radiation accumulated Temperature
° F ° F %  mph  mph  W/m*m  in ° F
17:10 67.0 10.8 11 22 42 E OK 598.0 3.97 71.0
16:10 65.0 11.2 12 20 38 E OK 302.0 3.97 67.0
15:10 63.0 13.1 14 17 33 E OK 51.0 3.97 66.0
14:10 60.0 12.2 15 8 21 ENE OK 6.0 3.97 56.0
13:10 61.0 11.5 14 10 23 ENE OK 0.0 3.97 58.0
12:10 62.0 12.3 14 13 36 ENE OK 0.0 3.97 59.0
11:10 64.0 13.9 14 17 35 E OK 0.0 3.97 61.0
10:10 64.0 16.9 16 17 34 E OK 0.0 3.97 61.0
9:10 64.0 18.3 17 11 23 E OK 0.0 3.97 60.0
8:10 65.0 17.7 16 8 26 ENE OK 0.0 3.97 61.0
7:10 63.0 18.8 18 7 16 ENE OK 0.0 3.97 57.0
6:10 59.0 19.1 21 0 1 E OK 0.0 3.97 49.0
5:10 61.0 20.8 21 0 4 SSW OK 0.0 3.97 51.0
4:10 63.0 21.3 20 2 7 ESE OK 0.0 3.97 55.0
3:10 61.0 21.9 22 2 6 E OK 0.0 3.97 52.0
2:10 59.0 25.1 27 0 7 S OK 0.0 3.97 52.0
1:10 68.0 21.6 17 2 9 SE OK 0.0 3.97 61.0
0:10 75.0 22.6 14 4 11 ESE OK 121.0 3.97 80.0
23:10 80.0 22.8 12 7 13 E OK 332.0 3.97 84.0
22:10 81.0 23.6 12 7 19 E OK 525.0 3.97 93.0
21:10 82.0 20.1 10 8 16 E OK 676.0 3.97 96.0


Archives of past fires: 2008 2007 2006 2005 2004 2003 2002 2001


Forest mapping: 2008 2007 2006 2005 2004 2003 2002 2001


FireMapper™ Specifications: Instrument

FireMapper™ References: Publications

FireMapper™ Tools- image analysis software: ftp downloads page

For Further Information: contact Dr. Philip J. Riggan



FireMapper™ has been developed through a Research Joint Venture with Space Instruments, Inc., and support from the National Fire Plan, Forest Service International Programs, the U.S. Department of Agriculture, the Joint Fire Sciences Program, and the U.S. Agency for International Development.
