Fire Science

Thermal mapping



Mammoth Geyser Basin in Yellowstone NP
on the afternoon of October 12, 2006



As viewed by the FireMapper™ system
in reflected red, near-InfraRed and thermal-InfraRed light


Click on the image above to view a larger Zoomify (JPEG) image with 15 meter resolution
(opens a new browser window)

Images were collected from the PSW Airborne Sciences Aircraft flying over the area of the Mammoth Geyser Basin at 15:03 MDT.



Image 1:
Image mosaic from Mammoth Geyser Basin.

This RGB image shows reflected red light at 650 nm in red, reflected NIR at 850 nm in green, and thermal IR at 8 - 12 um in blue.


Download this image as a .5 meter-resolution TIFF.


Click on the image above to view a larger Zoomify (JPEG) image with .5 meter resolution
(opens a new browser window)



Image 2:
Image mosaic from Mammoth Geyser Basin in a Google Earth overlay.


View the Geyser area in Google Earth.
Locations approximate, low resolution version.


Click on the image above to view the full-resolution image
(opens a new browser window)





FireMapper™ Specifications: Instrument

FireMapper™ References: Publications

FireMapper™ Tools image analysis software ftp downloads page

For Further Information: contact Dr. Philip J. Riggan





FireMapper™ has been developed through a Research Joint Venture with Space Instruments, Inc., and support from the National Fire Plan, Forest Service International Programs, the U.S. Department of Agriculture, the Joint Fire Sciences Program, and the U.S. Agency for International Development.
