Fire Science: Wildfire Monitoring and Prediction

Fire Imaging
Freeway Complex Fire, Orange County, CA
17 November 2008 between 17:00 and 17:47 PST

As viewed by the FireMapper™ Thermal-Imaging Radiometer

Click on the image above to view a larger Zoomify image with pan and zoom
or view the JPEG version
(opens a new browser window)

Ground surface temperatures as viewed from above at 8-12 micrometers wavelength in the thermal infrared.


Image 1: Thermal Mosaic
Plan view of fire. Warmer tones (red, orange, yellow) represent recent or active combustion; areas of light gray are cooling ash or warm bare ground and the low temperatures of unburned forest and cool ground are shown in darker gray (see chart above).

Purple is used to show cooling ash but could be associated with bare ground away from fire.

Click on the image above to view a larger JPEG image
(opens a new browser window)


Data from multiple visits may be included in this imagery. Click one of the links below to open a separate viewer with more display options.

(Zoom in to view over topographic map)




Weather conditions at time of data collection :
Corona station KAJO; data from NOAA ROMAN system.

Past Weather Conditions for Corona
Observations prior to selected time: November 17, 2008 - 17:00 PST
Weather Conditions at November 17, 2008 - 16:56 PST

16:56 24 Hour Max 24 Hour Min
Temperature 79.0° F 90.9 at 12:56 43.9 at 3:56
Dew Point 29.1° F 36.9 at 10:56 21.0 at 18:56
Relative Humidity 16% 60 at 5:56 11 at 18:56
Wind Speed 8 mph from W 12 at 21:56 0 at 2:56
Wind Gust - 18 at 21:56 18 at 21:56
Pressure 29.49 in 29.59 at 7:56 29.46 at 17:56
Sea level pressure 30.06 in 30.16 at 7:56 30.02 at 17:56
Altimeter 30.07 in 30.17 at 7:56 30.04 at 17:56
Weather conditions clear - -
Visibility 10.00 miles 10.00 at 17:56 8.00 at 2:56

Archives of past fires: 2008 2007 2006 2005 2004 2003 2002 2001

Forest mapping: 2008 2007 2006 2005 2004 2003 2002 2001

FireMapper™ Specifications: Instrument

FireMapper™ References: Publications

FireMapper™ Tools- image analysis software: ftp downloads page

For Further Information: contact Dr. Philip J. Riggan


FireMapper™ has been developed through a Research Joint Venture with Space Instruments, Inc., and support from the National Fire Plan, Forest Service International Programs, the U.S. Department of Agriculture, the Joint Fire Sciences Program, and the U.S. Agency for International Development.
